Pre-Cast Column Connection Design

Rating:
6

Description


DESIGN OF COLUMN FOUNDATION CONNECTIONS/BASE PLATE
Design Code:
B.S. 8110 Part 1
Input Data:
  • Columns Size
  • column width
  • column depth
  • Column Loads
  • Axial Load
  • Column Moment(major axis)
  • projection length
  • dist from plate edge to holding down bolts
  • yeild strength of plate
  • yeild strength of bolts

Calculation Reference
Precast Concrete Design
Concrete Design
BS8110

Calculation Preview

Uploaded
14 Aug 2011
Last Modified
14 Aug 2011
File Size:
83.50 Kb
Downloads:
272
File Version:
1.0
File Author:
Wilfred B. Lotino
Rating:
6
